Point-7 / Aluminium windsurfing booms

Alu+Pro.

Real control. Every session.

Aluminium construction, an ergonomic curve and a setup that makes sense. From wave sessions to freeride blasting, Alu+ Pro keeps your focus where it belongs: on the water.

Point-7 Alu+ Pro boom head and grip detail
Your connection to the session. Alu+ Pro
Aluminium construction.
4 Size options
140 to 250 cm overall
50 cm Extension range
on every size
2 cm Adjustment steps
for precise setup

Four sizes. One Alu+ Pro range.

Get the
right fit.

Choose the length that covers your sail’s boom setting. Then compare grip diameter, mast fitting and tail width.

Complete Point-7 Alu+ Pro aluminium boom, original catalogue image
Alu+ Pro. Aluminium windsurfing boom.
Round tube profile.

Alu+ Pro

140

140-190 cm

Wave / Freestyle

26 mm tube 29 mm including grip

Alu+ Pro

160

160-210 cm

Wave / Freestyle / Freeride

26 mm tube 29 mm including grip

Alu+ Pro

180

180-230 cm

Freeride / Slalom

28 mm tube 31 mm including grip

Alu+ Pro

200

200-250 cm

Freeride / Slalom

28 mm tube 31 mm including grip

All four sizes use round tubes. The smaller two have a 29 mm finished grip diameter; the larger two have a 31 mm finished grip diameter.

Compare specifications

Made for the next session

Grip.
Set. Go.

The curve is where the design starts. Your front and back arms need a comfortable working position. Grip and adjustment make that position easy to repeat.

Original Point-7 Alu+ Wave 140-190 grip and graphics

Comfort in your hands

Find your position.

A soft, sanded anti-slip grip and harness-line reference marks help you settle into your setup.

Point-7 Alu+ Pro boom length adjustment clip

50 cm range / 2 cm steps

Set. Lock. Sail.

Double push pins connect the body and tail. Set both sides equally and check that the pins are fully engaged.

Point-7 Alu+ Pro internal tail and outhaul fitting

Geometry for the sail

Room to work.

Internal tails across the range. The 180 and 200 add pulley fittings for adjustable outhaul routing. Check the additional control lines your setup needs.

Match the mast. The tilting head follows your chosen boom height. The 140 has an RDM fitting. The 160, 180 and 200 have SDM fittings, with an RDM adapter included on the 160. For RDM use on the 180 or 200, confirm the required adapter with our team .

The numbers that matter

Your sail.
Your size.

Tube diameter excludes the grip. Use the finished grip diameter to compare the size you will hold in your hands.

Alu+ Pro / Length, grip and weight comparison.
Model Intended use Length Tube Ø With grip Ø Weight
140 Wave / Freestyle 140-190 cm 26 mm 29 mm 2.3 kg
160 Wave / Freestyle / Freeride 160-210 cm 26 mm 29 mm 2.7 kg
180 Freeride / Slalom 180-230 cm 28 mm 31 mm 2.8 kg
200 Freeride / Slalom 200-250 cm 28 mm 31 mm 2.9 kg

Weights have a ±5% tolerance. Use your sail’s specified boom length to select the range. Check the shop for current prices and availability.

Full geometry, mast fitting and adjustment
Sail areas are a guide. Confirm the required boom length and mast fitting for your exact setup.
Model Sail area guide Mast fitting Widest point Internal tail width Tail fitting Extension / step
140 3.3-6.4 m² RDM 38 cm 12 cm Internal 50 cm / 2 cm
160 4.7-7.2 m² SDM / RDM adapter included 41.5 cm 12 cm Internal 50 cm / 2 cm
180 5.4-8.5 m² SDM 48 cm 14.5 cm Internal 50 cm / 2 cm
200 6.8-9.4 m² SDM 51 cm 14.5 cm Internal 50 cm / 2 cm

Straight from Point-7

Let’s talk
booms.

Understand what changes the feel of your rig. Watch the Point-7 guide, then choose the connection that suits the way you sail.

The Point-7 boom guide. Open video ↗

Before you rig

Clear answers.
Better choices.

Start with your sail model, its boom setting and your mast diameter. We will help you match the rest.

Who is Alu+ Pro for?
Alu+ Pro is a practical aluminium option for riders who value comfort, straightforward adjustment and everyday value. Choose the size and geometry for your sail and the sessions you enjoy.
Which size should I choose?
Choose a range that covers the boom length specified for your sail. Then check mast fitting and tail clearance. The sail-area ranges in the table are a guide, not a substitute for your sail’s rigging settings.
Does every size include an RDM adapter?
The 140 has an RDM fitting. The 160 is supplied with an RDM adapter for its SDM head. The 180 and 200 are listed with SDM fittings; ask us about the adapter needed for RDM use .
Can I use adjustable outhaul?
The 180 and 200 have pulley tails intended for adjustable outhaul routing. Confirm which lines and accessories you need for the complete system.
